High Strength Hat and Omega Profile Roll Forming Machine

High Strength Hat and Omega Profile Roll Forming Machine：

Precision Engineering for Industrial Structural Components The Hat and Omega Profile Roll Forming Machine from Hebei Xinnuo Roll Forming Machinery Co., Ltd. represents the pinnacle of specialized cold-forming technology for the structural steel sector. Unlike standard roof panel machines, hat profiles (also known as hat channels or omega purlins) are defined by their complex geometry—a flat top surface flanked by two angled webs and horizontal flanges. This specific shape provides an exceptional strength-to-weight ratio, making it an indispensable component for wall interior support systems, roof purlins in commercial warehouses, and internal rails for shipping containers. Our engineering team has optimized this production line to handle the significant material stress encountered during the simultaneous multi-angle bending process required for these profiles.

Advanced Drive System and High-Torque Performance A critical challenge in producing hat profiles is the high resistance caused by the deep, near-90-degree bends on both sides of the profile. To counteract this, Xinnuo’s GB009 series is equipped with a powerhouse 11.0 kW high-torque motor. This energy is transmitted through a 1.5-inch heavy-duty single-row chain drive system, ensuring that the rollers maintain constant speed even when forming thicker 2.0mm steel sheets. The core of the machine’s stability lies in its Φ76mm solid shafts, crafted from high-grade 45# steel and precision-ground to eliminate deflection. These robust components work in harmony to produce profiles that are perfectly straight, without any longitudinal twist or surface scarring, meeting the strictest architectural tolerances.

Durability and Roll Forming Metallurgy Longevity is at the heart of every Xinnuo build. The main chassis is constructed from 350H industrial-grade steel, providing a rigid foundation that absorbs vibrations and prevents long-term frame distortion. The forming rollers are manufactured from premium GCr15 bearing steel, which undergoes a rigorous vacuum quenching process followed by hard chrome plating. This treatment achieves a surface hardness of HRC 58-62, drastically reducing wear during high-volume production cycles. Furthermore, the 16mm precision-ground middle plates maintain the critical alignment of each station, ensuring that the symmetrical wings of the hat profile remain consistent from the first meter to the last.

Intelligent Automation and Global Service Excellence Each Xinnuo Hat Profile Machine features a fully integrated PLC automation system (available in Delta or Siemens versions) with a multi-language touch screen interface. This allows operators to easily input product lengths and batch quantities, while the synchronous hydraulic post-cutting system ensures every profile is sheared cleanly with zero waste. Beyond the equipment, Hebei Xinnuo offers a comprehensive support package, including 24/7 remote technical assistance, detailed video installation guides, and a streamlined global logistics network. With equipment installed across the Middle East, Southeast Asia, and Europe, Xinnuo remains the trusted partner for manufacturers seeking reliable, high-output structural steel production solutions.
